Generator Excitation System with 96.20% Efficiency and 110V to 690V Voltage Range Featuring Automatic Voltage Regulator (AVR)
Datos del producto:
| Nombre de la marca: | Wawushan |
| Certificación: | ISO9001 |
| Número de modelo: | EX-202508 |
Pago y Envío Términos:
| Minimum Order Quantity: | 1 |
|---|---|
| Precio: | 5000-60000USD |
| Delivery Time: | 3 Months |
| Payment Terms: | T/T |
| Supply Ability: | 300 Set Per Unit |
|
Información detallada |
|||
| Tipo de control: | Regulador automático de voltaje (AVR) | Disposición: | Horizontal |
|---|---|---|---|
| Corriente nominal: | 5A | Tipo de montaje: | Montado en panel o gabinete |
| Color: | Verde | Eficiencia nominal: | 96% |
| cuchilla del corredor: | Fijado | Eficiencia: | 96,20% |
| Resaltar: | 96.20% Efficiency Generator Excitation System,110V to 690V Voltage Range Excitation System,Automatic Voltage Regulator AVR Excitation System |
||
Descripción de producto
Generator Excitation System
The Generator Excitation System is engineered to ensure stable and efficient operation of electrical generators by providing precise control over voltage output. With a current range of 0 to 500A, this system is suitable for various generator sizes and applications across industrial power plants, commercial facilities, and renewable energy installations.
Featuring a horizontal layout for easy installation and maintenance access, this system incorporates an Automatic Voltage Regulator (AVR) that continuously monitors and adjusts excitation current to maintain stable output voltage under varying load conditions.
Key Features
- Current Range: 0 to 500A
- Control Type: Automatic Voltage Regulator (AVR)
- Input AC Voltage: 100V
- Horizontal Layout for optimal space utilization
- Fixed Runner Blade design
- 96.20% efficiency rating for reduced energy loss
- 50Hz rated frequency for global compatibility
- Robust construction for long-term reliability
Technical Specifications
| Parameter | Specification |
|---|---|
| Layout | Horizontal |
| Runner Blade | Fixed |
| Control Type | Automatic Voltage Regulator (AVR) |
| Rated Efficiency | 96% |
| Type | Synchronous Generator |
| Mounting Type | Panel Mounted or Cabinet Mounted |
| Color | Green |
| Input AC Voltage | 100V |
| Dimension | 3M x 3M x 2.5M |
| Output Capacity | 100KW to 20MW |
Applications
The Wawushan EX-202501 Generator Excitation System is ideal for power plants, industrial facilities, emergency power supply systems, renewable energy installations, and backup power systems for hospitals, data centers, and telecommunications facilities.
Customization & Support
Custom solutions available with model EX-202501, ISO9001 certified. Supply capacity of 300 sets per unit with minimum order quantity of 1 set. Delivery time: 3 months. Comprehensive technical support including installation guidance, maintenance services, and personnel training.
