Pelton Hydro Turbine with 1-200 MW Power Capacity for 100m-800m Water Head and Dual Nozzles
Datos del producto:
| Nombre de la marca: | Wawushan |
| Certificación: | ISO9001 |
| Número de modelo: | CJA-202507 |
Pago y Envío Términos:
| Minimum Order Quantity: | 1 |
|---|---|
| Precio: | 50000 |
| Detalles de empaquetado: | Estándar |
| Delivery Time: | 6 Months |
| Payment Terms: | L/C |
| Supply Ability: | 100 Set Per Unit |
|
Información detallada |
|||
| Tasa de flujo: | 1-200 M3/s | Nivel de ruido: | bajo |
|---|---|---|---|
| Número de boquilla: | Bocas duales | Cabeza: | 50-1000 M |
| Capacidad de potencia: | 1-200 MW | Anillo de la boquilla: | Acero Inoxidable 0Cr13Ni4Mo (CA6NM) |
| Velocidad nominal: | 750r/min | Tipo de corredor: | Solo o Multi-jet |
| Resaltar: | 1-200 MW Power Capacity Pelton Hydro Turbine,100m-800m Water Head Water Impulse Turbine,Dual Nozzles High-Pressure Turbine |
||
Descripción de producto
Pelton Hydro Turbine: High-Efficiency Power Generation
The Pelton Hydro Turbine is engineered for exceptional efficiency in converting high-pressure water energy into mechanical power. Designed specifically for water heads ranging from 100 to 800 meters, this high-pressure turbine excels in mountainous regions and locations with steep water drops, delivering reliable performance across diverse hydroelectric applications.
Key Features & Specifications
- Power Capacity: 1 to 200 MW
- Head Range: 50-1000 meters
- Flow Rate: 1-200 m³/s
- Dual Nozzle Configuration
- Rated Speed: 750 r/min
- Efficiency: Up to 90% or higher
- Runner Type: Single or Multi-Jet
- Bucket Design: Double Cup or Split Bucket
- Low Noise Operation
- High Strength & Anti-Corrosion Properties
Technical Parameters
| Flow Rate | 1-200 m³/s |
| Runner Type | Single or Multi-Jet |
| Rated Speed | 750 r/min |
| Efficiency | Up to 90% or higher |
| Design Head | 200m-600m |
| Head Range | 50-1000 m |
| Bucket Design | Double Cup or Split Bucket |
| Noise Level | Low |
| Power Capacity | 1-200 MW |
| Type | Impulse Turbine |
Application Scenarios
This high-efficiency turbine is ideal for mountainous regions with steep water drops, remote hydropower plants, industrial power stations, and community-scale generation projects. Its impulse design efficiently handles variable water flows, making it versatile for sustainable energy development in high-pressure environments.
Customization Options
Wawushan offers customized Pelton Hydro Turbine solutions (Model CJA-2025) with ISO9001 certification. Features include stainless steel nozzle rings (0Cr13Ni4Mo/CA6NM) for enhanced corrosion resistance. Available with flexible ordering options: minimum order of 1 set, supply capacity of 100 sets, with delivery within 6 months and L/C payment terms.
Technical Support & Services
Our comprehensive support includes installation assistance, commissioning, maintenance guidance, troubleshooting, and preventive maintenance services. We provide training programs for technical staff, spare parts availability, and upgrade/retrofitting options to ensure optimal performance and extended service life.
Quality Assurance
Manufactured in China with ISO9001 certification, our Pelton Hydro Turbines feature robust construction, corrosion-resistant materials, and proven reliability for long-term operation in demanding hydroelectric environments.
