Stainless Steel Nozzle Ring Pelton Hydro Turbine with Dual Nozzles for High Head 100m-800m Applications
Datos del producto:
| Nombre de la marca: | Wawushan |
| Certificación: | ISO9001 |
| Número de modelo: | CJA-202508 |
Pago y Envío Términos:
| Minimum Order Quantity: | 1 |
|---|---|
| Precio: | 50000 |
| Detalles de empaquetado: | Estándar |
| Delivery Time: | 6 Months |
| Payment Terms: | L/C |
| Supply Ability: | 100 Set Per Unit |
|
Información detallada |
|||
| Velocidad nominal: | 750r/min | Diseño de cubo: | Taza doble o cubo dividido |
|---|---|---|---|
| cabeza del agua: | 100 a 800 metros | Anillo de la boquilla: | Acero Inoxidable 0Cr13Ni4Mo (CA6NM) |
| Tipo: | Turbina de impulso | Tipo de corredor: | Solo o Multi-jet |
| cabeza del diseño: | 200m-600m | Nombre del producto: | Turbina hidráulica de Pelton |
| Resaltar: | Stainless Steel Nozzle Ring Pelton Hydro Turbine,Dual Nozzles Water Impulse Turbine,High Head 100m-800m Hydro Jet Turbine |
||
Descripción de producto
Pelton Hydro Turbine - High-Efficiency Power Generation
The Pelton Hydro Turbine is a state-of-the-art reaction hydro turbine engineered for exceptional performance in high-pressure water head applications. Designed for efficiency and durability, this high-efficiency turbine harnesses energy from water heads ranging from 50 to 1000 meters, with optimal operation between 100 and 800 meters.
Featuring a premium stainless steel 0Cr13Ni4Mo (CA6NM) nozzle ring, this turbine delivers superior strength and exceptional corrosion resistance, ensuring reliable operation in harsh environments and high-pressure conditions.
Key Features
- Impulse Turbine Type with Dual Nozzle Configuration
- Design Head Range: 200m-600m
- Double Cup or Split Bucket Design
- High Strength and Anti-Corrosion Construction
- Optimized for Various Hydro Power Applications
- Water Jet Turbine Technology for Maximum Energy Conversion
Technical Specifications
| Product Name | Pelton Hydro Turbine |
| Type | Impulse Turbine |
| Power Capacity | 1-200 MW |
| Nozzle Number | Dual Nozzles |
| Nozzle Ring Material | Stainless Steel 0Cr13Ni4Mo (CA6NM) |
| Runner Type | Single or Multi-Jet |
| Bucket Design | Double Cup or Split Bucket |
| Efficiency | Up to 90% or Higher |
| Rated Speed | 750r/min |
Applications
The Wawushan CJA-2025 Pelton Hydro Turbine is engineered for high-head hydroelectric power generation in mountainous regions and hilly terrain. Ideal for small to medium-sized hydroelectric plants, industrial power generation, and remote off-grid power solutions.
Model Specifications
Model: CJA-2025
Certification: ISO9001
Flow Rate: 1-200 M³/s
Noise Level: Low Operation
Customization Options
Wawushan offers customizable Pelton Hydro Turbine solutions tailored to your specific project requirements. With a minimum order quantity of 1 set and supply capacity of 100 sets per unit time, we provide flexible solutions for diverse hydroelectric applications.
Pricing & Delivery
Price: $50,000 per unit
Delivery Time: 6 months
Payment Terms: L/C
Technical Support & Services
Our comprehensive support includes expert guidance on installation, operation, and maintenance. We provide detailed documentation, training sessions, on-site inspections, and preventive maintenance to ensure optimal performance and longevity of your turbine investment.
